IR110X125X40-EGS INA

All dimensions

1. Inner (d) MM 110
2. Outer (D) MM 125
3. Width (B) MM 40
4. Inner (d) Inch 4.3307
5. Outer (D) Inch 4.9213
6. Width (B) Inch 1.5748
7. Raceway diameter inner ring (F) mm 125
8. Width (b) mm 40

Suffix description

1. EGS Inner Ring With Machined Twist-Free Raceway (For Contact Seals)

Technical details

1. Availability 16 pcs
2. Brand INA
3. Item number IR110X125X40-EGS INA
4. Also known as 0002461660000

5. EAN 4054362407881
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.89

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. ECLASS number 23-05-91-90
2. ECLASS2 number 23-05-91-90
3. Medias description Inner ring IR..-EGS, cylindrical

Downloads and links

1. Link to manufacturer Link to manufacturer
