HUB3464 BRB

All dimensions

1. Inner (d) MM 34
2. Outer (D) MM 64
3. Width (B) MM 37
4. Inner (d) Inch 1.3386
5. Outer (D) Inch 2.5197
6. Width (B) Inch 1.4567

Technical details

1. Availability 94 pcs
2. Brand BRB
3. Item number HUB3464 BRB
4. Also known as 309726BA
   540466B
   BAH-0092

5. Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 0.448

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RS - Rubber Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Split Inner ring / Outer ring Split inner ring
