HK5025 INA

All dimensions

1. Inner (d) MM 50
2. Outer (D) MM 58
3. Width (B) MM 25
4. Inner (d) Inch 1.9685
5. Outer (D) Inch 2.2835
6. Width (B) Inch 0.9843
7. Under roller diameter (F w) mm 50
8. Width (C) mm 25

Technical details

1. Availability 94 pcs
2. Brand INA
3. Item number HK5025 INA
4. Also known as 0001936660000

5. EAN 4012801006323
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.088

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 84000
2. Radial Dynamic Load Rating Cr (N) 38500
3. Limiting speed (n G) 5300
4. Limiting speed for grease lubrication (n G Grease) 3150
5. Reference speed (n ϑr) 4000
6. ECLASS number 23-05-09-05
7. ECLASS2 number 23-05-09-05
8. Medias description Drawn cup needle roller bearing open end HK, single row, with cage
