HK5024-2RS-AS1-A-L271 INA

All dimensions

1. Inner (d) MM 50
2. Outer (D) MM 58
3. Width (B) MM 24
4. Inner (d) Inch 1.9685
5. Outer (D) Inch 2.2835
6. Width (B) Inch 0.9449
7. Under roller diameter (F w) mm 50

Suffix description

1. 2RS Lip Seals On Both Sides
2. AS1 Needle Roller Bearing With Lubrication Hole(s) In The Outer Ring. A Figure Following The As Indicates The Number Of Holes
3. A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
4. L271 Anti Wear Protection Grease

Technical details

1. Availability 0 pcs
2. Brand INA
3. Item number HK5024-2RS-AS1-A-L271 INA
4. Also known as 0013828880968

5. EAN 4054364527877
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.086

Product Properties

1. Seal 2RS - Rubber Seal on Two Sides

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 63000
2. Limiting speed (n G) 3150
3. Limiting speed for grease lubrication (n G Grease) 3150
4. ECLASS number 23-05-09-05
5. ECLASS2 number 23-05-09-05
