HK3038-ZW INA

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 37
3. Width (B) MM 38
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 1.4567
6. Width (B) Inch 1.4961
7. Under roller diameter (F w) mm 30

Suffix description

1. ZW Double Row Needle Roller And Cage Assembly

Technical details

1. Availability 53 pcs
2. Brand INA
3. Item number HK3038-ZW INA
4. Also known as 0001810050000

5. EAN 4012802429473
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.076

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 79000
2. Radial Dynamic Load Rating Cr (N) 37500
3. Limiting speed (n G) 8600
4. Reference speed (n ϑr) 6200
5. ECLASS number 23-05-09-05
6. ECLASS2 number 23-05-09-05
7. Medias description Drawn cup needle roller bearings with open ends HK, to DIN 618/ISO 3245
