HK3020-2RS-AS1-L271 INA

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 37
3. Width (B) MM 20
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 1.4567
6. Width (B) Inch 0.7874
7. Under roller diameter (F w) mm 30

Suffix description

1. 2RS Lip Seals On Both Sides
2. AS1 Needle Roller Bearing With Lubrication Hole(s) In The Outer Ring. A Figure Following The As Indicates The Number Of Holes
3. L271 Anti Wear Protection Grease

Technical details

1. Availability 39 pcs
2. Brand INA
3. Item number HK3020-2RS-AS1-L271 INA
4. Also known as 0012646050968

5. EAN 4047643184908
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.039

Product Properties

1. Seal 2RS - Rubber Seal on Two Sides

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 29000
2. Limiting speed (n G) 5200
3. Limiting speed for grease lubrication (n G Grease) 5200
4. ECLASS number 23-05-09-05
5. ECLASS2 number 23-05-09-05
