HK2524-2RS-L271 INA

All dimensions

1. Inner (d) MM 25,00
2. Outer (D) MM 32,00
3. Width (B) MM 24,00
4. Inner (d) Inch 0.9843
5. Outer (D) Inch 1.2598
6. Width (B) Inch 0.9449
7. Under roller diameter (F w) mm 25,00

Suffix description

1. 2RS Lip Seals On Both Sides
2. L271 Anti Wear Protection Grease

Technical details

1. Availability 102 pcs
2. Brand INA
3. Item number HK2524-2RS-L271 INA
4. Also known as 0007018580968

5. EAN 4054371703394
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.047

Product Properties

1. Seal 2RS - Rubber Seal on Two Sides

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 33000
2. Radial Dynamic Load Rating Cr (N) 19900
3. Basic static load rating, radial (C 0r) "33000.0000"
4. Limiting speed (n G) "6100.0000"
5. Limiting speed for grease lubrication (n G Grease) "6100.0000"
6. ECLASS number 23-05-09-05
7. ECLASS2 number 23-05-09-05
8. Medias description Drawn cup needle roller bearings with open ends HK..-2RS, lip seals on both sides, to DIN 618

Downloads and links

1. Link to manufacturer Link to manufacturer
