HC71914E.2RSD.T.P4S.UL SLF Fraureuth

All dimensions

1. Inner (d) MM 70,00
2. Outer (D) MM 100,00
3. Width (B) MM 16,00
4. Inner (d) Inch 2.7559
5. Outer (D) Inch 3.9370
6. Width (B) Inch 0.6299

Suffix description

1. E 25° Contact Angle
2. 2RSD Lip Seals On Both Sides, Non-Contact
3. T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
4. P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
5. UL Single Bearing, Universal, Light Preload

Technical details

1. Availability 57 pcs
2. Brand SLF Fraureuth
3. Item number HC71914E.2RSD.T.P4S.UL SLF Fraureuth
4. Also known as S71914ACBGA/HCP4A

5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.34

Product Properties

1. Seal 2RU - Two Seals / Non Contact Type
2. Cage Type TB - Hard Fiber Cage
3. Precision H4 - Hybrid / Ceramic Balls / P4
4. Contact Angle 25 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
