HC6316-C3 FAG

2.789,66 ex VAT
€ 3.375,49 in VAT
€ 3.375,49 in VAT
2.789,66 ex VAT

Temporarily sold out
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

HC6316-C3 FAG

Stock
not in stock
Brand FAG
Article number HC6316-C3 FAG
Inside diameter 80mm
Outside diameter 170mm
Width 39mm
Product description
Help with this product

Downloads and links

Similar to: HC6316-C3 FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 80
  2. Outer (D) MM 170
  3. Width (B) MM 39
  4. Inner (d) Inch 3.1496
  5. Outer (D) Inch 6.6929
  6. Width (B) Inch 1.5354
  7. Width (b) mm 39

Suffix description

  1. C3 Internal Clearance Larger Than Normal

Technical details

  1. Availability 0 pcs
  2. Brand FAG
  3. Item number HC6316-C3 FAG
  4. Also known as 0660962860030
  5. EAN 4012802511963
  6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

  1. Weight (kg) 3.69

Product Properties

  1. Bore C - Cylindrical Bore
  2. Seal No Seal
  3. Cage Type S - Steel or Standard Cage
  4. External Modification No External Modification
  5. Radial Internal Play C3 Internal Play (Higher than Cn)
  6. Precision Standard Precision
  7. Lubrication Standard Lubrication
  8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
  9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 110000
  2. Radial Dynamic Load Rating Cr (N) 150000
  3. Limiting speed (n G) 6400
  4. Reference speed (n ϑr) 6000
  5. ECLASS number 23-05-08-01
  6. ECLASS2 number 23-05-08-01
  7. Medias description Deep groove ball bearing HC63, single row, cf. DIN 625-1

Downloads and links

  1. Link to manufacturer Link to manufacturer
Show all details Show less
