GYE35-KRR-B-FA107-VA-HLA INA

All dimensions

1. Inner (d) MM 35
2. Outer (D) MM 72
3. Width (B) MM 42,9
4. Inner (d) Inch 1.378
5. Outer (D) Inch 2.8346
6. Width (B) Inch 1.689
7. Outside diameter (D SP) mm 72
8. Width (b) mm 42,9

Suffix description

1. KRR Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
2. B Bearing With Spherical Outer Ring
3. FA107 Bearing With Lubrication Holes On The Locating Side
4. VA Stainless Steel
5. HLA Factory Location Code, No Additional Meaning. Can Be Used As Standard

Technical details

1. Availability 6 pcs
2. Brand INA
3. Item number GYE35-KRR-B-FA107-VA-HLA INA
4. Also known as 0518022790000
   GYE35-KRR-B-FA107-VA

5. EAN 4054362377832
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.439

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment FA107 + VA

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 15300
