GVK100-208-KTT-B-AS2/V INA

All dimensions

1. Inner (d) MM 25,4
2. Outer (D) MM 80
3. Width (B) MM 36,5
4. Inner (d) Inch 1
5. Outer (D) Inch 3.1496
6. Width (B) Inch 1.437
7. Outside diameter (D SP) mm 80
8. Width (b) mm 36,5

Suffix description

1. KTT Triple Lip Seals On Both Sides Of The Bearing (T Type Seal)
2. B Bearing With Spherical Outer Ring
3. AS2/V Bearing Outer Ring With Two Lubrication Holes In Offset Planes

Technical details

1. Availability 152 pcs
2. Brand INA
3. Item number GVK100-208-KTT-B-AS2/V INA
4. Also known as 0504194630000
   GW208PPB3 AH08

5. EAN 4054362376668
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.74

Product Properties

1. Seal 3T - Tripple Seal
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 19800

Downloads and links

1. Link to manufacturer Link to manufacturer
