GSH40-XL-2RSR-B INA

All dimensions

1. Inner (d) MM 40
2. Outer (D) MM 80
3. Width (B) MM 22
4. Inner (d) Inch 1.5748
5. Outer (D) Inch 3.1496
6. Width (B) Inch 0.8661
7. Outside diameter (D SP) mm 80
8. Width (b) mm 22
9. Locking collar total width (B 1) mm 38

Suffix description

1. XL X-Life
2. 2RSR Lip Seals On Both Sides (Vulcanised)
3. B Spherical Outside Diameter

Technical details

1. Availability 73 pcs
2. Brand INA
3. Item number GSH40-XL-2RSR-B INA
4. Also known as 0009555660000
   GSH40-2RSR-B

5. EAN 4012802823158
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.54

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 19700
2. Radial Dynamic Load Rating Cr (N) 31000
3. ECLASS number 23-05-08-02
4. ECLASS2 number 23-05-08-02
5. Medias description Radial insert ball bearings GSH..-2RSR-B, spherical outer ring, location by adapter sleeve, RSR seals on both sides

Downloads and links

1. X-life brochure X-life brochure
2. Link to manufacturer Link to manufacturer
