GRAE45-XL-NPP-B INA

All dimensions

1. Inner (d) MM 45
2. Outer (D) MM 85
3. Width (B) MM 43,7
4. Inner (d) Inch 1.7717
5. Outer (D) Inch 3.3465
6. Width (B) Inch 1.7205
7. Outside diameter (D SP) mm 85
8. Width (b) mm 30,2
9. Locking collar total width (B 1) mm 43,8

Suffix description

1. XL X-Life
2. NPP Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded)
3. B Bearing With Spherical Outer Ring
4. FA106 Bearing Subjected To Special Noise Testing
5. L460 NSF-H1 Approval, Lubricants Registered As H1 Or Certified To ISO 21469 Are Considered Food Grade

Technical details

1. Availability 25 pcs
2. Brand INA
3. Item number GRAE45-XL-NPP-B INA
4. Also known as 0008495020000
   1245-45ECG
   AEL209
   EN209S
   ES209
   FH209
   GRAE45KRRB
   GRAE45-NPP-B
   GRAE45RRB
   INS-SXV-45M
   KH209
   SA209
   UE209
   WG2M45UL
   YET209

5. EAN 4012802800722
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.65

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 20400
2. Radial Dynamic Load Rating Cr (N) 34500
3. ECLASS number 23-05-08-02
4. ECLASS2 number 23-05-08-02
5. Medias description Radial insert ball bearing GRAE..-XL-NPP-B
