GRAE30-208-NPP-B-AH01 INA

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 80
3. Width (B) MM 43,7
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 3.1496
6. Width (B) Inch 1.7205

Suffix description

1. NPP Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded)
2. B Bearing With Spherical Outer Ring
3. AH01 Dimensions Can Deviate From Basic Part Number, Internal Clearance Is C3 (Larger Than Normal) and Protected Against Corrosion By Corrotect® Special Coating

Technical details

1. Availability 27 pcs
2. Brand INA
3. Item number GRAE30-208-NPP-B-AH01 INA
4. Also known as 0035684820000

5. EAN 4012802822144
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.72

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. ECLASS number 23-05-08-02
2. ECLASS2 number 23-05-08-02
