GRAE25-NPP-B-FA106 INA

All dimensions

1. Inner (d) MM 25,00
2. Outer (D) MM 52,00
3. Width (B) MM 31,00
4. Inner (d) Inch 0.9843
5. Outer (D) Inch 2.0472
6. Width (B) Inch 1.2205
7. Outside diameter (D SP) mm 52,00
8. Width (b) mm 21,40
9. Locking collar total width (B 1) mm 31,00

Suffix description

1. NPP Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded)
2. B Bearing With Spherical Outer Ring
3. FA106 Bearing Subjected To Special Noise Testing

Technical details

1. Availability 98 pcs
2. Brand INA
3. Item number GRAE25-NPP-B-FA106 INA
4. Also known as 0008401650000
   YET205

5. EAN 4012802788792
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.18

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment FA106

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 7800
2. Radial Dynamic Load Rating Cr (N) 14900
3. Basic static load rating, radial (C 0r) "7800.0000"
4. ECLASS number 23-05-08-02
5. ECLASS2 number 23-05-08-02
6. Medias description Radial insert ball bearing GRAE..-NPP-B
