GRA103-NPP-B-AS2/V INA

All dimensions

1. Inner (d) MM 30,16
2. Outer (D) MM 62
3. Width (B) MM 35,7
4. Inner (d) Inch 1.1875
5. Outer (D) Inch 2.4409
6. Width (B) Inch 1.4055
7. Outside diameter (D SP) mm 62
8. Width (b) mm 23,8
9. Locking collar total width (B 1) mm 35,8

Suffix description

1. NPP Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded)
2. B Bearing With Spherical Outer Ring
3. AS2/V Bearing Outer Ring With Two Lubrication Holes In Offset Planes

Technical details

1. Availability 6 pcs
2. Brand INA
3. Item number GRA103-NPP-B-AS2/V INA
4. Also known as 0502720550000
   YET206-103

5. EAN 4047643164122
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.299

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 11300
