GRA102-NPP-B-AS2/V INA

All dimensions

1. Inner (d) MM 28,58
2. Outer (D) MM 62
3. Width (B) MM 35,7
4. Inner (d) Inch 1.125
5. Outer (D) Inch 2.4409
6. Width (B) Inch 1.4055

Suffix description

1. NPP Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded)
2. B Bearing With Spherical Outer Ring
3. AS2/V Bearing Outer Ring With Two Lubrication Holes In Offset Planes

Technical details

1. Availability 0 pcs
2. Brand INA
3. Item number GRA102-NPP-B-AS2/V INA
4. Also known as GRA102-XL-NPP-B-AS2/V
   YET206-102

5. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.327

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 11300
2. Radial Dynamic Load Rating Cr (N) 20700
3. ECLASS number 23-05-08-02
4. ECLASS2 number 23-05-08-02
5. Medias description Radial insert ball bearing GRA..-NPP-B-AS2/V

Downloads and links

1. Link to Manufacturer Link to Manufacturer
