GLCTEY20 INA

Housing and Bearing (assembly)

Stock
30 pcs in stock and ready for shipment
Brand INA
Article number GLCTEY20 INA
Inside diameter 20mm
Product description

The GLCTEY20 INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: GLCTEY20 INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 20
  2. Inner (d) Inch 0.7874
  3. Flange width (L) mm 66,5
  4. Height flange (H) mm 90,5
  5. Total height unit (U) mm 33

Technical details

  1. Availability 30 pcs
  2. Brand INA
  3. Item number GLCTEY20 INA
  4. Also known as 0009256830000
  5. EAN 4012802806076
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.31

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 6600
  2. Radial Dynamic Load Rating Cr (N) 13600
  3. ECLASS number 23-05-16-02
  4. ECLASS2 number 23-05-16-02
  5. Medias description Flanged housing unit GLCTEY
