GE40-XL-KTT-B INA

All dimensions

1. Inner (d) MM 40
2. Outer (D) MM 80
3. Width (B) MM 56,5
4. Inner (d) Inch 1.5748
5. Outer (D) Inch 3.1496
6. Width (B) Inch 2.2244
7. Outside diameter (D SP) mm 80
8. Width (b) mm 42,9
9. Locking collar total width (B 1) mm 56,5

Suffix description

1. XL X-Life
2. KTT Triple Lip Seals On Both Sides Of The Bearing (T Type Seal)
3. B Bearing With Spherical Outer Ring
4. >A Alteration In Internal Construction. Identical To Old Notation

Technical details

1. Availability 47 pcs
2. Brand INA
3. Item number GE40-XL-KTT-B INA
4. Also known as 0008516200000
   GE40KPPB3
   GE40-KTT-B

5. EAN 4012802800166
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.75

Product Properties

1. Seal 3T - Tripple Seal
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 19800
2. Radial Dynamic Load Rating Cr (N) 34500
3. ECLASS number 23-05-08-02
4. ECLASS2 number 23-05-08-02
5. Medias description Radial insert ball bearings GE..-KTT-B, spherical outer ring, location by eccentric locking collar, T seals on both sides
