GE30-XL-KRR-B-2C INA

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 62
3. Width (B) MM 48,4
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 2.4409
6. Width (B) Inch 1.9055
7. Outside diameter (D SP) mm 62
8. Width (b) mm 36,5
9. Locking collar total width (B 1) mm 48,5

Suffix description

1. XL X-Life
2. KRR Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
3. B Bearing With Spherical Outer Ring
4. 2C Flinger Shields On Both Sides

Technical details

1. Availability 19 pcs
2. Brand INA
3. Item number GE30-XL-KRR-B-2C INA
4. Also known as 0008284910000
   GE30KRRB CC
   GE30-KRR-B-2C
   YEL206-2FF

5. EAN 4012802793222
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.38

Product Properties

1. Seal 2C - Flinger Shield On Both Sides
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 11300
2. Radial Dynamic Load Rating Cr (N) 20700
3. ECLASS number 23-05-08-02
4. ECLASS2 number 23-05-08-02
5. Medias description Radial insert ball bearings GE..-KRR-B-2C, spherical outer ring, location by eccentric locking collar, R seals on both sides
