FLCTE15-XL INA

Housing and Bearing (assembly)

Stock
59 pcs in stock and ready for shipment
Brand INA
Article number FLCTE15-XL INA
Inside diameter 15mm
Outside diameter 81mm
Width 30,5mm
Product description

The FLCTE15-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: FLCTE15-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 15
  2. Outer (D) MM 81
  3. Width (B) MM 30,5
  4. Inner (d) Inch 0.5906
  5. Outer (D) Inch 3.189
  6. Width (B) Inch 1.2008
  7. Flange width (L) mm 58,7
  8. Height flange (H) mm 81
  9. Total height unit (U) mm 30,5

Suffix description

  1. XL X-Life

Technical details

  1. Availability 59 pcs
  2. Brand INA
  3. Item number FLCTE15-XL INA
  4. Also known as 0008315300000
    FLCTE15
    FYTF15FM
    RAE15NPPB + LCTE03
    YET203/15 + FYTF503
  5. EAN 4012802791600
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.3

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 4750
  2. Radial Dynamic Load Rating Cr (N) 10100
  3. ECLASS number 23-05-16-02
  4. ECLASS2 number 23-05-16-02
  5. Medias description Housing units FLCTE, two-bolt flanged housing units, cast iron, eccentric locking collar, P seals, without relubrication facility

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
Show all details Show less
