Brand INA
Article number EGW38-E40-Z INA
Inside diameter 38mm
Outside diameter 62mm
Width 1,5mm
Product description

The EGW38-E40-Z INA is a bushing. Bushings have a very simple, one-piece cylindrical design without rolling elements. Instead, they have a sliding contact where the shaft slides into the bore. This construction makes these bushings a cost-effective and reliable solution. Additionally, they are easy to install and require little installation space. The direct contact between the bushing and the shaft results in greater friction between the surfaces. Compared to roller bearings, they have lower speed and load capacities. Bushings are primarily used for rotating, oscillating, and linear movements.

The EGW38-E40-Z INA features a maintenance-free PTFE sliding contact. PTFE is a special plastic. During the initial running-in period of the bushing, particles from the PTFE sliding layer are transferred to the opposing mating surface. This fills in small imperfections, creating a smooth surface. Thanks to this maintenance-free sliding contact, the bushing does not need to be lubricated at any point during its entire lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: EGW38-E40-Z INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 38
  2. Outer (D) MM 62
  3. Width (B) MM 1,5
  4. Inner (d) Inch 1.4961
  5. Outer (D) Inch 2.4409
  6. Width (B) Inch 0.0591
  7. Wall thickness (s 3) mm 1,5

Suffix description

  1. E40 Steel Backing With Sintered Layer Of Tin Bronze. Pore Filling And Covering Layer (5 To 30µm) Of PTFE With Friction-Reduction Additives
  2. Z Schaeffler Factory Code

Technical details

  1. Availability 15 pcs
  2. Brand INA
  3. Item number EGW38-E40-Z INA
  4. Also known as 0705336600000
  5. EAN 4012802756159
  6. Category Bushing

Weight and Dimensions

  1. Weight (kg) 0.021

Data from Schaeffler (medias)

  1. Basic dynamic load rating, axial (C a) 264000
  2. Axial Static Load Rating C0a (N) 471000
  3. Basic static load rating, axial (C 0a) 471000
  4. Axial Dynamic Load Rating Ca (N) 264000
  5. ECLASS number 23-05-01-91
  6. ECLASS2 number 23-05-01-91
  7. Medias description Thrust washer, maintenance-free, material in accordance with ISO 3547-4, with steel backing
