EGW14-E50-Y INA

€ 1,37 ex VAT
€ 1,66 incl. VAT
€ 1,66 incl. VAT
€ 1,37 ex VAT
Guaranteed same day shipment on orders placed before 17.00h (CEST)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

EGW14-E50-Y INA

Bushing

Stock
2,420 pcs in stock and ready for shipment
Brand INA
Article number EGW14-E50-Y INA
Inside diameter 14,00mm
Outside diameter 26,00mm
Width 1,50mm
Product description

The EGW14-E50-Y INA is a bushing. Bushings have a very simple, one-piece cylindrical design without rolling elements. Instead, they have a sliding contact where the shaft slides into the bore. This construction makes these bushings a cost-effective and reliable solution. Additionally, they are easy to install and require little installation space. The direct contact between the bushing and the shaft results in greater friction between the surfaces. Compared to roller bearings, they have lower speed and load capacities. Bushings are primarily used for rotating, oscillating, and linear movements.

Read more Show less
Help with this product

Downloads and links

Similar to: EGW14-E50-Y INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 14,00
  2. Outer (D) MM 26,00
  3. Width (B) MM 1,50
  4. Inner (d) Inch 0.5512
  5. Outer (D) Inch 1.0236
  6. Width (B) Inch 0.0591
  7. Wall thickness (s 3) mm 1,50

Suffix description

  1. E50 Steel Backing With Sintered Layer Of Tin Bronze. Pore Filling And Covering Layer (0,3 And 0,4mm, Resp.) Of PTFE With Friction-Reducing Additives
  2. Y Schaeffler Factory Code

Technical details

  1. Availability 2,420 pcs
  2. Brand INA
  3. Item number EGW14-E50-Y INA
  4. Also known as 0708753830000
    PAW14P20
  5. EAN 4012802757897
  6. Category Bushing

Weight and Dimensions

  1. Weight (kg) 0.001

Data from Schaeffler (medias)

  1. Basic dynamic load rating, axial (C a) "26400.0000"
  2. Axial Static Load Rating C0a (N) 52800
  3. Basic static load rating, axial (C 0a) "52800.0000"
  4. Axial Dynamic Load Rating Ca (N) 26400
  5. ECLASS number 23-05-01-91
  6. ECLASS2 number 23-05-01-91
  7. Medias description Thrust washer, low-maintenance, material in accordance with ISO 3547-4, with steel backing

Downloads and links

  1. Link to manufacturer Link to manufacturer
