EGB10050-E50-Y INA

Bushing

Stock	not in stock
Brand	INA
Article number	EGB10050-E50-Y INA
Inside diameter	100mm
Outside diameter	105mm
Width	50mm

Product description

The EGB10050-E50-Y INA is a bushing. Bushings have a very simple, one-piece cylindrical design without rolling elements. Instead, they have a sliding contact where the shaft slides into the bore. This construction makes these bushings a cost-effective and reliable solution. Additionally, they are easy to install and require little installation space. The direct contact between the bushing and the shaft results in greater friction between the surfaces. Compared to roller bearings, they have lower speed and load capacities. Bushings are primarily used for rotating, oscillating, and linear movements.

Start a chat
Call us at: +31 (0)85 00 22 247
Email us at: help@247industries.com Response within 24h

Downloads and links

Link to manufacturer

Similar to: EGB10050-E50-Y INA

Loading similair products

Product specifications

Inside diameter 100mm
Outside diameter 105mm
Width 50mm

All dimensions

Inner (d) MM 100
Outer (D) MM 105
Width (B) MM 50
Inner (d) Inch 3.937
Outer (D) Inch 4.1339
Width (B) Inch 1.9685
Outer diameter (D o) mm 105
Width (b) mm 50

Suffix description

E50 Steel Backing With Sintered Layer Of Tin Bronze. Pore Filling And Covering Layer (0,3 And 0,4mm, Resp.) Of PTFE With Friction-Reducing Additives
Y Schaeffler Factory Code

Technical details

Availability 0 pcs
Brand INA
Item number EGB10050-E50-Y INA
Also known as 0713549300000
EAN 4012802757453
Category Bushing

Weight and Dimensions

Weight (kg) 0.28

Data from Schaeffler (medias)

Radial Static Load Rating C0r (N) 700000
Radial Dynamic Load Rating Cr (N) 350000
ECLASS number 23-05-01-91
ECLASS2 number 23-05-01-91
Medias description Metal/polymer composite plain bush, low-maintenance, ISO 3547, with steel backing
