E45-KTT-B-L285/70-OSE INA

All dimensions

1. Inner (d) MM 45
2. Outer (D) MM 85
3. Width (B) MM 42,9
4. Inner (d) Inch 1.7717
5. Outer (D) Inch 3.3465
6. Width (B) Inch 1.689
7. Outside diameter (D SP) mm 85
8. Width (b) mm 42,9

Suffix description

1. KTT Triple Lip Seals On Both Sides Of The Bearing (T Type Seal)
2. B Bearing With Spherical Outer Ring
3. L285/70 Renolit GA3 Greasefill, Temp Range -30 ~ 120ºC, 70% Filling
4. OSE Bearing Without Locking Element (Eccentric Locking Collar)

Technical details

1. Availability 0 pcs
2. Brand INA
3. Item number E45-KTT-B-L285/70-OSE INA
4. Also known as 0042044410000

5. EAN 4012802820881
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.64

Product Properties

1. Seal T - T-seal
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 20400
