CSEA020-HLE INA

All dimensions

1. Inner (d) MM 50,80
2. Outer (D) MM 63,50
3. Width (B) MM 6,35
4. Inner (d) Inch 2.0000
5. Outer (D) Inch 2.5000
6. Width (B) Inch 0.2500
7. Width (b) mm 6,35

Suffix description

1. HLE Factory Location Code, No Additional Meaning. Can Be Used As Standard

Technical details

1. Availability 3 pcs
2. Brand INA
3. Item number CSEA020-HLE INA
4. Also known as 0077299010000
   6000046
   FPAA200
   KA020ARO
   L15QA200
   NBA5006

5. EAN 4054362037835
6. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.059

Product Properties

1. Seal No Seal
2. Cage Type M - Brass Cage
3. Precision Standard Precision
4. Contact Angle 30 degrees
5. Pairing No pairing
6. Axial Internal Clearance / Preload No Preload
7. Lubrication Standard Lubrication

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 3100
2. Radial Dynamic Load Rating Cr (N) 3300
3. Basic static load rating, radial (C 0r) "3100.0000"
4. ECLASS number 23-05-08-03
5. ECLASS2 number 23-05-08-03
6. Medias description Thin Section Bearing CSEA, angular contact ball bearing
