CSCF050-HLE INA

All dimensions

1. Inner (d) MM 127
2. Outer (D) MM 165,1
3. Width (B) MM 19,05
4. Inner (d) Inch 5
5. Outer (D) Inch 6.5
6. Width (B) Inch 0.75
7. Width (b) mm 19,05

Suffix description

1. HLE Factory Location Code, No Additional Meaning. Can Be Used As Standard

Technical details

1. Availability 1 pc
2. Brand INA
3. Item number CSCF050-HLE INA
4. Also known as 0090805110000
   6000046
   FPCF500
   KF050CP0
   KF050CPO
   L10VA500T
   NBC12719

5. EAN 4054362037521
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.959

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type P - Plastic Molded Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision ABEC.1 Tolerances
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 24700
2. Radial Dynamic Load Rating Cr (N) 25500
3. Basic static load rating, radial (C 0r) "24700.0000"
4. Limiting speed (n G) 3700
5. ECLASS number 23-05-08-01
6. ECLASS2 number 23-05-08-01
7. Medias description Thin Section Bearing CSCF, deep groove ball bearing
