CSCA025-HLE INA

All dimensions

1. Inner (d) MM 63,50
2. Outer (D) MM 76,20
3. Width (B) MM 6,35
4. Inner (d) Inch 2.5000
5. Outer (D) Inch 3.0000
6. Width (B) Inch 0.2500
7. Width (b) mm 6,35

Suffix description

1. HLE Factory Location Code, No Additional Meaning. Can Be Used As Standard

Technical details

1. Availability 18 pcs
2. Brand INA
3. Item number CSCA025-HLE INA
4. Also known as 0097498960000
   6000046
   FPCA208
   KA025CP0
   KA025CPO
   L10QA208T
   NBC6306

5. EAN 4012802208702
6. Category Four Point Contact Ball Bearing

Weight and Dimensions

1. Weight (kg) 0.06

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type M - Brass Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision ABEC.1 Tolerances
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
10. Split Inner ring / Outer ring Standard

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 3250
2. Radial Dynamic Load Rating Cr (N) 3600
3. Basic static load rating, radial (C 0r) "3250.0000"
4. Limiting speed (n G) "8500.0000"
5. ECLASS number 23-05-08-01
6. ECLASS2 number 23-05-08-01
7. Medias description Thin Section Bearing CSCA, deep groove ball bearing
