CRB20/76-XL INA

All dimensions

1. Inner (d) MM 20
2. Outer (D) MM 77,5
3. Width (B) MM 36
4. Inner (d) Inch 0.7874
5. Outer (D) Inch 3.0512
6. Width (B) Inch 1.4173
7. Locking collar total width (B 1) mm 31
8. Width total (B 2) mm 36

Suffix description

1. XL X-Life

Technical details

1. Availability 75 pcs
2. Brand INA
3. Item number CRB20/76-XL INA
4. Also known as 0008347180000
   CRB20/76

5. EAN 4012802789270
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.3

Product Properties

1. Seal 2L - LS-seal at Both Sides
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 6600
2. Radial Dynamic Load Rating Cr (N) 13600
3. ECLASS number 23-05-08-02
4. ECLASS2 number 23-05-08-02
5. Medias description Radial insert ball bearings CRB, with rubber interliner, location by eccentric locking collar, P seals on both sides

Downloads and links

1. X-life brochure X-life brochure
2. Link to manufacturer Link to manufacturer
