CF10VUU-A THK

All dimensions

1. Inner (d) MM 10
2. Outer (D) MM 22
3. Width (B) MM 36,2
4. Inner (d) Inch 0.3937
5. Outer (D) Inch 0.8661
6. Width (B) Inch 1.4252

Suffix description

1. V Full Complement Type
2. UU Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded), Temperature Range -30 ~ 100℃. If Letter R Is In The Suffix, Than The Cam Follower Is With Crowned Outer Ring, Otherwise It's A Cylindrical Running Surface (X)
3. A Stud With A Hexagon Socket

Technical details

1. Availability 0 pcs
2. Brand THK
3. Item number CF10VUU-A THK
4. Category Cam Follower

Weight and Dimensions

1. Weight (kg) 0.046

Product Properties

1. Seal 2L - LS-seal at Both Sides
2. Excenterring Other Mounting Method
3. Running Surface Cylindrical
