BSB60120-SU FAG

All dimensions

1. Inner (d) MM 60,00
2. Outer (D) MM 120,00
3. Width (B) MM 20,00
4. Inner (d) Inch 2.3622
5. Outer (D) Inch 4.7244
6. Width (B) Inch 0.7874
7. Width (b) mm 20,00

Suffix description

1. SU Universal Bearing; Single Bearings Can Be Used In Sets In Any Combination Required

Technical details

1. Availability 5 pcs
2. Brand FAG
3. Item number BSB60120-SU FAG
4. Also known as 0687461560000

5. EAN 4047643081054
6. Category Angular Contact Thrust Ball Bearings, Single Direction

Weight and Dimensions

1. Weight (kg) 1.1

Product Properties

1. Cage Type S - Steel or Standard Cage
2. Precision Standard Precision

Data from Schaeffler (medias)

1. Basic dynamic load rating, axial (C a) "71000.0000"
2. Basic static load rating, axial (C 0a) "196000.0000"
3. Limiting speed for grease lubrication (n G Grease) "3800.0000"
4. Thermally safe operating speed (n ϑ) "2300.0000"
5. ECLASS number 23-05-10-02
6. ECLASS2 number 23-05-10-02
