BSB0300623UMP3 SRIY5 RHP

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 62
3. Width (B) MM 45
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 2.4409
6. Width (B) Inch 1.7717

Suffix description

1. 3UM Triple Set, Universally Faced Bearing, Medium Preload
2. P3 Dimensional Accuracy P4, Running Accuracy P2
3. SRI Lubricant, Operating Temperature -10 ~ 110°C
4. Y Unknown
5. 5 Standard Single Pack. Bearings In Polythene Bags Or Hizex Film Are Placed In Individual Cardboard Boxes. The Individual Boxes Are Then Placed In A Cardboard Outer Carton And Polystrene Filled

Technical details

1. Availability 1 pc
2. Brand RHP
3. Item number BSB0300623UMP3 SRIY5 RHP
4. EAN 00747023094509
5. Category Angular Contact Thrust Ball Bearings, Single Direction

Weight and Dimensions

1. Weight (kg) 0.75

Product Properties

1. Cage Type P - Plastic Molded Cage
2. Precision Dim. Acc. P4, Run. Acc. P2
