BS2-2205-2CS/VT143 Neutral

All dimensions

1. Inner (d) MM 25
2. Outer (D) MM 52
3. Width (B) MM 23
4. Inner (d) Inch 0.9843
5. Outer (D) Inch 2.0472
6. Width (B) Inch 0.9055

Suffix description

1. 2CS Sheet Steel Reinforced Contact Seal Of Acrylonitrile-Butadiene Rubber (NBR) On Both Sides Of The Bearing. Annular Groove And Three Lubrication Holes In The Outer Ring Covered With A Polymer Band. Lubricated With An Extreme Pressure Bearing Grease According To Temperature Range -20 ~ 110℃, Grease Fill 25% To 35%
2. VT143 Extreme Pressure Grease. Grease Fill 25 to 35% With SKF LGEP2 Grease

Technical details

1. Availability 0 pcs
2. Brand Neutral
3. Item number BS2-2205-2CS/VT143 Neutral
4. Also known as BS2-2205-2RS/VT143
   WS22205-E1-2RSR
   WS22205-E1-XL-2RSR

5. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 0.31

Product Properties

1. Bore C - Cylindrical Bore
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal 2RS - Rubber Seal on Two Sides
4. Cage Type S - Steel or Standard Cage
5. Radial Internal Play Cn Normal Internal Play
6. Precision VT - Extreme Pressure Grease, LGEP2
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
