BEAS15/45Z 7 P60 SNFA

All dimensions

1. Inner (d) MM 15,00
2. Outer (D) MM 45,00
3. Width (B) MM 25,00
4. Inner (d) Inch 0.5906
5. Outer (D) Inch 1.7717
6. Width (B) Inch 0.9843

Suffix description

1. Z Shield Of Pressed Sheet Steel On Both Sides Of The Bearing
2. 7 Accuracy To ABEC7 (ISO Tolerance Class 4)
3. P Injection Moulded Cage Of Polyamide 66
4. 60 Contact Angle 60°

Technical details

1. Availability 0 pcs
2. Brand SNFA
3. Item number BEAS15/45Z 7 P60 SNFA
4. Also known as BEAS015045-2Z
   ZKLN1545-2Z

5. Category Angular Contact Thrust Ball Bearings, Double Direction

Weight and Dimensions

1. Weight (kg) 0.21

Product Properties

1. Cage Type P - Plastic Molded Cage
2. Precision P4 Precision (Higher than P5)
