BA6 SKF

Single-direction thrust ball bearing

Stock
58 pcs in stock and ready for shipment
Brand SKF
Article number BA6 SKF
Inside diameter 6mm
Outside diameter 14mm
Width 5mm
Product description

The BA6 SKF belongs to the single direction thrust ball bearings, also called ball thrust bearings or axial deep groove ball bearings. These bearings consist of a shaft ring, a housing ring and a ball and cage assembly. Thrust ball bearings have an open design. The balls make them suitable for high rotational speeds.

Single direction thrust ball bearings can only be loaded axially in one direction. A shaft can be locked in one direction this way. Radially, they must not be loaded. The shaft ring is attached to the shaft. This ring rotates along with the shaft. The housing ring has a slightly larger bore diameter, allowing the shaft to pass with some clearance.

As thrust ball bearings can be disassembled, the components can easily be mounted separately. Be careful not to mix up the shaft and housing ring when you are assembling the bearing. The housing ring of the BA6 SKF has a flat seat. As a result, this bearing cannot compensate for any misalignment between the shaft and housing.

Read more Show less
Help with this product

Similar to: BA6 SKF

Product
Dimensions/Properties
Stock
Price ex VAT
AKL6-HLC INA
AKL6-HLC INA
Guaranteed same day shipment on orders placed before 18:00h (CET)
16,50 ex VAT
  • Inside diameter 6mm
  • Outside diameter 14mm
  • Width 5mm
AKL6-HLC INA
Guaranteed same day shipment on orders placed before 18:00h (CET)

31 pcs
16,50 ex VAT

Product specifications

All dimensions

  1. Inner (d) MM 6
  2. Outer (D) MM 14
  3. Width (B) MM 5
  4. Inner (d) Inch 0.2362
  5. Outer (D) Inch 0.5512
  6. Width (B) Inch 0.1969

Technical details

  1. Availability 58 pcs
  2. Brand SKF
  3. Item number BA6 SKF
  4. Also known as AKL6
    AKL6-HLC
  5. EAN 7316577732521
  6. Category Thrust Ball Bearing Single Direction

Weight and Dimensions

  1. Weight (kg) 0.0045

Product Properties

  1. Cage Type S - Steel or Standard Cage
  2. Precision Standard Precision
