B71911E.T.P4S.TUM SLF Fraureuth

All dimensions

1. Inner (d) MM 55
2. Outer (D) MM 80
3. Width (B) MM 39
4. Inner (d) Inch 2.1654
5. Outer (D) Inch 3.1496
6. Width (B) Inch 1.5354

Suffix description

1. E 25° Contact Angle
2. T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
3. P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
4. TUM Set Of 3 Universal Bearings, Medium Preload

Technical details

1. Availability 9 pcs
2. Brand SLF Fraureuth
3. Item number B71911E.T.P4S.TUM SLF Fraureuth
4. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.54

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4S Precision (Higher than P4)
4. Contact Angle 25 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload TM - 3 Univ Bearings Med. Preload
7. Lubrication Standard Lubrication
