B7017X3 TA U EP7 RHP

All dimensions

1. Inner (d) MM 85
2. Outer (D) MM 130
3. Width (B) MM 22
4. Inner (d) Inch 3.3465
5. Outer (D) Inch 5.1181
6. Width (B) Inch 0.8661

Suffix description

1. X3 25° Contact Angle
2. TA One Piece Outer Ring Centred Machined Laminated Phenolic
3. U Universal Mounting
4. EP7 Extra Precision Tolerance Class 7. Super Precision Metric Bearings To ISO Grade 4, Abec-7, And BS292 EP7 Tolerances (Also Inch Bearings When Supplied To Abec-7 Tolerances)

Technical details

1. Availability 0 pcs
2. Brand RHP
3. Item number B7017X3 TA U EP7 RHP
4. Also known as 7017ACD/P4A
   B7017-E-T-P4S

5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.89

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 25 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload No Preload
7. Lubrication Standard Lubrication
