81192-M INA

All dimensions

1. Inner (d) MM 460
2. Outer (D) MM 560
3. Width (B) MM 80
4. Inner (d) Inch 18.1102
5. Outer (D) Inch 22.0472
6. Width (B) Inch 3.1496
7. Height (T) mm 80

Suffix description

1. M Machined Brass Cage, Located On The Rolling Elements

Technical details

1. Availability 0 pcs
2. Brand INA
3. Item number 81192-M INA
4. Also known as 0016350260000

5. EAN 4047643148641
6. Category Cylindrical Roller Thrust Bearing

Weight and Dimensions

1. Weight (kg) 41

Product Properties

1. Cage Type M - Brass Cage
2. Precision Standard Precision

Data from Schaeffler (medias)

1. Axial Static Load Rating C0a (N) 8700000
2. Axial Dynamic Load Rating Ca (N) 1840000
3. Limiting speed (n G) 560
4. Reference speed (n ϑr) 177
5. ECLASS number 23-05-11-01
6. ECLASS2 number 23-05-11-01
7. Medias description Axial cylindrical roller bearing 811..-M, single row

Downloads and links

1. Link to manufacturer Link to manufacturer
