7MC3-6320L1 B C3 NTN

All dimensions

1. Inner (d) MM 100
2. Outer (D) MM 215
3. Width (B) MM 47
4. Inner (d) Inch 3.937
5. Outer (D) Inch 8.4646
6. Width (B) Inch 1.8504

Suffix description

1. L1B Machined Brass Cage Centered On Balls
2. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 0 pcs
2. Brand NTN
3. Item number 7MC3-6320L1 B C3 NTN
4. Also known as 6320M/C3VL0241
   6320-M-J20AA-C3

5. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 8.4

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type M - Brass Cage
4. External Modification No External Modification
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Breakdown Voltage 1000v
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
