77R24 Peer

All dimensions

1. Inner (d) MM 38,1
2. Outer (D) MM 66,68
3. Width (B) MM 14,59
4. Inner (d) Inch 1.5
5. Outer (D) Inch 2.625
6. Width (B) Inch 0.5625

Technical details

1. Availability 0 pcs
2. Brand Peer
3. Item number 77R24 Peer
4. Also known as EE13-2Z
   KLNJ1.1/2-2Z
   R24.2Z

5. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.141

Product Properties

1. Bore C - Cylindrical Bore
2. Seal ZZ/2Z - Steel Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
