7602025-TVP FAG

Axial angular contact ball bearings 7602, single direction, with contact angle α = 60°, restricted tolerances

Stock
37 pcs in stock and ready for shipment
Brand FAG
Article number 7602025-TVP FAG
Inside diameter 25,00mm
Outside diameter 52,00mm
Width 15,00mm
Product description
Read more Show less
Help with this product

Downloads and links

Similar to: 7602025-TVP FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 25,00
  2. Outer (D) MM 52,00
  3. Width (B) MM 15,00
  4. Inner (d) Inch 0.9843
  5. Outer (D) Inch 2.0472
  6. Width (B) Inch 0.5906
  7. Width (b) mm 15,00

Suffix description

  1. TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding

Technical details

  1. Availability 37 pcs
  2. Brand FAG
  3. Item number 7602025-TVP FAG
  4. Also known as 0191192160000
    25TAC52DB
    BSA205
    BSA205C
    BSA205CGA
    BSD2552DB
    MM25BS52DUH
  5. EAN 4012801166683
  6. Category Angular Contact Thrust Ball Bearings, Single Direction

Weight and Dimensions

  1. Weight (kg) 0.1478

Product Properties

  1. Cage Type P - Plastic Molded Cage
  2. Precision Standard Precision

Data from Schaeffler (medias)

  1. Basic dynamic load rating, axial (C a) "23200.0000"
  2. Axial Static Load Rating C0a (N) 50000
  3. Basic static load rating, axial (C 0a) "50000.0000"
  4. Axial Dynamic Load Rating Ca (N) 23200
  5. Limiting speed for grease lubrication (n G Grease) "8000.0000"
  6. Thermally safe operating speed (n ϑ) "4500.0000"
  7. ECLASS number 23-05-10-02
  8. ECLASS2 number 23-05-10-02
  9. Medias description Axial angular contact ball bearing 7602..-TVP, single direction, no screw mounting
