7602020-TVP FAG

All dimensions

1. Inner (d) MM 20,00
2. Outer (D) MM 47,00
3. Width (B) MM 14,00
4. Inner (d) Inch 0.7874
5. Outer (D) Inch 1.8504
6. Width (B) Inch 0.5512
7. Width (b) mm 14,00

Suffix description

1. TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding

Technical details

1. Availability 29 pcs
2. Brand FAG
3. Item number 7602020-TVP FAG
4. Also known as 0167265960000
   20TAC47DB
   BSA204
   BSD2047DB
   MM20BS47DUH

5. EAN 4012801016483
6. Category Angular Contact Thrust Ball Bearings, Single Direction

Weight and Dimensions

1. Weight (kg) 0.12

Product Properties

1. Cage Type P - Plastic Molded Cage
2. Precision Standard Precision

Data from Schaeffler (medias)

1. Basic dynamic load rating, axial (C a) "20300.0000"
2. Axial Static Load Rating C0a (N) 38000
3. Basic static load rating, axial (C 0a) "41500.0000"
4. Axial Dynamic Load Rating Ca (N) 19100
5. Limiting speed for grease lubrication (n G Grease) "9200.0000"
6. Thermally safe operating speed (n ϑ) "5000.0000"
7. ECLASS number 23-05-10-02
8. ECLASS2 number 23-05-10-02
9. Medias description Axial angular contact ball bearing 7602..-TVP, single direction, no screw mounting
