75BER19STXV1VSULP3 NSK

All dimensions

1. Inner (d) MM 75
2. Outer (D) MM 115
3. Width (B) MM 20
4. Inner (d) Inch 2.9528
5. Outer (D) Inch 4.5276
6. Width (B) Inch 0.7874

Suffix description

1. S All Steel Bearing (SUJ2)
2. TX Outer Ring Guided Phenolic Cage
3. V1V Non-Contact Rubber Seals
4. SUL Single Bearing, Universally Ground, Light Preload
5. P3 Dimensional Accuracy P4, Running Accuracy P2

Technical details

1. Availability 0 pcs
2. Brand NSK
3. Item number 75BER19STXV1VSULP3 NSK
4. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.679

Product Properties

1. Seal 2RU - Two Seals / Non Contact Type
2. Cage Type TB - Hard Fiber Cage
3. Precision Dim. Acc. P4, Run. Acc. P2
4. Contact Angle 25 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
