7409BG NSK

All dimensions

1. Inner (d) MM 45
2. Outer (D) MM 120
3. Width (B) MM 29
4. Inner (d) Inch 1.7717
5. Outer (D) Inch 4.7244
6. Width (B) Inch 1.1417

Suffix description

1. B 40° Contact Angle
2. G Ball Bearing, Angular Contact, Single Row, Flush Ground Inner And Outer Ring Side Faces

Technical details

1. Availability 23 pcs
2. Brand NSK
3. Item number 7409BG NSK
4. EAN 00029176019395
5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 1.79

Product Properties

1. Seal No Seal
2. Cage Type S - Steel or Standard Cage
3. Precision Standard Precision
4. Contact Angle 40 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload No Preload
7. Lubrication Standard Lubrication
