7317-B-XL-MP-P5-UO FAG

The 7317-B-XL-MP-P5-UO FAG is a single row angular contact ball bearing with a brass cage and no seal.

Stock
not in stock
Brand FAG
Article number 7317-B-XL-MP-P5-UO FAG
Inside diameter 85,00mm
Outside diameter 180,00mm
Width 41,00mm
Product description
Angular Contact Ball Single Row
Read more Show less

Similar to: 7317-B-XL-MP-P5-UO FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 85,00
  2. Outer (D) MM 180,00
  3. Width (B) MM 41,00

Technical details

  1. Availability 0 pcs
  2. Brand FAG
  3. Item number 7317-B-XL-MP-P5-UO FAG
  4. Technical details (B-XL-MP-P5-UO) B=(B-SKF)=40° Contact Angle. XL=X-Life. MP=Machined Brass Cage, Window Type, Rolling Element Riding. P5=Dimensional And Running Accuracy To ISO Tolerance Class 5. UO=Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance.
  5. Also known as 7317-B-MP-P5-UO
  6. Category Angular Contact Ball Bearing Single Row
  7. Weight (kg) 4.90
  8. Manufacturer Part Number (MPN) 7317-B-XL-MP-P5-UO
  9. Seal No Seal
  10. Cage Type M - Brass Cage
  11. Precision P5 Precision (Higher than P6)
  12. Contact Angle 40 Degrees
  13. Pairing G - Universal Pairing
  14. Axial Internal Clearance / Preload UO - Zero Clearance
  15. Lubrication Standard Lubrication
