7314BEGP SKF

193,12 ex VAT
€ 233,67 in VAT
€ 233,67 in VAT
193,12 ex VAT

135 similar products for 7314BEGP SKF in stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

7314BEGP SKF

Single row angular contact ball bearing

Stock
not in stock
Brand SKF
Article number 7314BEGP SKF
Inside diameter 70mm
Outside diameter 150mm
Width 35mm
Product description

The 7314BEGP SKF is a single row angular contact bearing. These bearings have solid inner- and outer rings. They owe their name to the contact angle that is created as the raceways of the inner and outer rings are offset from each other along the bearing axis. The bearing rings have one high and one low shoulder. Thanks to the low shoulder, a large number of balls can be incorporated in the bearing. Single row angular contact bearings can support high radial forces and axial forces in one direction. The greater the contact angle, the greater the axial load capacity of the bearing.

Help with this product

Similar to: 7314BEGP SKF

Product
Dimensions/Properties
Stock
Price ex VAT
7314-B-TVP FAG
7314-B-TVP FAG
Guaranteed same day shipment on orders placed before 18:00h (CET)
125,47 ex VAT
  • Inside diameter 70mm
  • Outside diameter 150mm
  • Width 35mm
7314-B-TVP FAG
Guaranteed same day shipment on orders placed before 18:00h (CET)

1 pc
125,47 ex VAT
7314-B-XL-TVP FAG
7314-B-XL-TVP FAG
Guaranteed same day shipment on orders placed before 18:00h (CET)
125,47 ex VAT
  • Inside diameter 70mm
  • Outside diameter 150mm
  • Width 35mm
7314-B-XL-TVP FAG
Guaranteed same day shipment on orders placed before 18:00h (CET)

18 pcs
125,47 ex VAT
7314BEP SKF
7314BEP SKF
Guaranteed same day shipment on orders placed before 18:00h (CET)
117,96 ex VAT
  • Inside diameter 70mm
  • Outside diameter 150mm
  • Width 35mm
7314BEP SKF
Guaranteed same day shipment on orders placed before 18:00h (CET)

112 pcs
117,96 ex VAT
7314BEAT85 NSK
7314BEAT85 NSK
Guaranteed same day shipment on orders placed before 18:00h (CET)
90,77 ex VAT
  • Inside diameter 70mm
  • Outside diameter 150mm
  • Width 35mm
7314BEAT85 NSK
Guaranteed same day shipment on orders placed before 18:00h (CET)

4 pcs
90,77 ex VAT

Product specifications

All dimensions

  1. Inner (d) MM 70
  2. Outer (D) MM 150
  3. Width (B) MM 35
  4. Inner (d) Inch 2.7559
  5. Outer (D) Inch 5.9055
  6. Width (B) Inch 1.378

Suffix description

  1. BE Single Row Angular Contact Ball Bearing With A 40° Contact Angle And Optimized Internal Design
  2. G Bearing For Paired Mounting In Random Order; When Arranged Back-To-Back Or Face-To-Face There Will Be Axial Internal Clearance
  3. P Injection Moulded Window-Type Cage Of Glass Fibre Reinforced Polyamide 6,6, Ball Centered

Technical details

  1. Availability 0 pcs
  2. Brand SKF
  3. Item number 7314BEGP SKF
  4. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

  1. Weight (kg) 2.67

Product Properties

  1. Seal No Seal
  2. Cage Type P - Plastic Molded Cage
  3. Precision Standard Precision
  4. Contact Angle 40 degrees
  5. Pairing No pairing
  6. Axial Internal Clearance / Preload No Preload
  7. Lubrication Standard Lubrication
