7307ETDUMP4 RHP

All dimensions

1. Inner (d) MM 35,00
2. Outer (D) MM 80,00
3. Width (B) MM 42,00
4. Inner (d) Inch 1.3780
5. Outer (D) Inch 3.1496
6. Width (B) Inch 1.6535

Suffix description

1. E 25° Contact Angle
2. T Machined Laminated Phenolic Cage (Single Row Radial or A. C. Bearings)
3. DUM Set Of 2 Universal Bearings, Medium Preload
4. P4 Dimensional & Running Accuracy To ISO Tolerance Class 4 (More Accurate Than P5)-Abec.7

Technical details

1. Availability 0 pcs
2. Brand RHP
3. Item number 7307ETDUMP4 RHP
4. Also known as 7307ACD/P4ADGB
   B7307-E-T-P4S-DUM

5. EAN 00747023125579
6. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.957

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 25 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload DM - 2 Univ Bearings Medium Pre
7. Lubrication Standard Lubrication
