7306BA TVPB Deutsche Kugellager Fabrik

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 72
3. Width (B) MM 19
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 2.8346
6. Width (B) Inch 0.748

Suffix description

1. BA 40° Contact Angle
2. TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring

Technical details

1. Availability 0 pcs
2. Brand Deutsche Kugellager Fabrik
3. Item number 7306BA TVPB Deutsche Kugellager Fabrik
4. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.331

Product Properties

1. Seal No Seal
2. Cage Type P - Plastic Molded Cage
3. Precision Standard Precision
4. Contact Angle 40 degrees
5. Pairing No pairing
6. Axial Internal Clearance / Preload No Preload
7. Lubrication Standard Lubrication
