7305B.TVP.P5 FAG

Single row angular contact ball bearing

Stock
not in stock
Brand FAG
Article number 7305B.TVP.P5 FAG
Inside diameter 25mm
Outside diameter 62mm
Width 17mm
Product description

The 7305B.TVP.P5 FAG is a single row angular contact bearing. These bearings have solid inner- and outer rings. They owe their name to the contact angle that is created as the raceways of the inner and outer rings are offset from each other along the bearing axis. The bearing rings have one high and one low shoulder. Thanks to the low shoulder, a large number of balls can be incorporated in the bearing. Single row angular contact bearings can support high radial forces and axial forces in one direction. The greater the contact angle, the greater the axial load capacity of the bearing.

Help with this product

Similar to: 7305B.TVP.P5 FAG

Product
Dimensions/Properties
Stock
Price ex VAT
7305-B-XL-TVP-P5 FAG
7305-B-XL-TVP-P5 FAG
Guaranteed same day shipment on orders placed before 18:00h (CET)
70,00 ex VAT
  • Inside diameter 25mm
  • Outside diameter 62mm
  • Width 17mm
7305-B-XL-TVP-P5 FAG
Guaranteed same day shipment on orders placed before 18:00h (CET)

7 pcs
70,00 ex VAT

Product specifications

All dimensions

  1. Inner (d) MM 25
  2. Outer (D) MM 62
  3. Width (B) MM 17
  4. Inner (d) Inch 0.9843
  5. Outer (D) Inch 2.4409
  6. Width (B) Inch 0.6693

Suffix description

  1. B 40° Contact Angle
  2. TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
  3. P5 Dimensional And Running Accuracy To ISO Tolerance Class 5

Technical details

  1. Availability 0 pcs
  2. Brand FAG
  3. Item number 7305B.TVP.P5 FAG
  4. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

  1. Weight (kg) 0.23

Product Properties

  1. Seal No Seal
  2. Cage Type P - Plastic Molded Cage
  3. Precision P5 Precision (Higher than P6)
  4. Contact Angle 40 degrees
  5. Pairing No pairing
  6. Axial Internal Clearance / Preload No Preload
  7. Lubrication Standard Lubrication
