7219C TR DUL P4 NSK

All dimensions

1. Inner (d) MM 95,00
2. Outer (D) MM 170,00
3. Width (B) MM 64,00
4. Inner (d) Inch 3.7402
5. Outer (D) Inch 6.6929
6. Width (B) Inch 2.5197

Suffix description

1. C 15° Contact Angle
2. TR Outer Ring Guided Phenolic Cage
3. DUL Set Of 2 Universal Bearings, Light Preload
4. P4 Dimensional & Running Accuracy To ISO Tolerance Class 4 (More Accurate Than P5)-Abec.7

Technical details

1. Availability 0 pcs
2. Brand NSK
3. Item number 7219C TR DUL P4 NSK
4. Also known as 7219CD/P4ADGA

5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 5.4

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 15 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload DL - 2 Univ Bearings Light Preload
7. Lubrication Standard Lubrication
